Pilz Pnoz V 30S 3S 1Sz/1O Relay 474790

Buy Pilz Pnoz V 30S 3S 1Sz/1O Relay 474790

Selected by motion safety specialists, the Pilz Pnoz V 30S 3S 1Sz/1O Relay 474790 handles both electromechanical and solid-state switching from one compact module. Three safety contacts manage conventional loads while the semiconductor output handles electronic devices requiring bounce-free switching. The auxiliary contact feeds diagnostic data to maintenance systems, and adjustable velocity thresholds cover everything from slow agitators to high-speed spindles without requiring multiple relay variants.

Key Features

• Dedicated standstill and overspeed detection for rotating equipment
• Three safety relay outputs (3S) for electromechanical load control
• One semiconductor output (1Sz) for electronic load switching
• One auxiliary output (1O) for diagnostic status monitoring
• Adjustable speed thresholds covering diverse application requirements
• Compatible with proximity sensors and encoder feedback devices

Typical Applications

• CNC spindle standstill verification before access
• Grinding wheel stopping confirmation
• Industrial mixer and agitator overspeed protection
• Conveyor drive maintenance access control
• Centrifuge deceleration monitoring
• Woodworking blade coast-down verification

Technical Specifications

• Product Name: Pilz Pnoz V 30S Safety Relay
• Model: 474790
• Type: Standstill and Overspeed Monitoring Safety Relay
• Operating Voltage: 24VDC
• Safety Relay Outputs: 3 safety-rated relay outputs (3S)
• Semiconductor Output: 1 semiconductor output (1Sz)
• Auxiliary Output: 1 auxiliary output (1O)
• Input Signals: Proximity sensors, encoder feedback
• Speed Thresholds: Adjustable
• Mounting: DIN rail mounting
• Safety Category: Up to Category 4 / PLe (EN ISO 13849-1)

📩 Contact us for pricing, availability, and delivery information.
