Pilz PNOZ 1 24VDC 3S/1O Safety Relay 24VDC 3.5W

Buy Pilz PNOZ 1 24VDC 3S/1O Safety Relay 24VDC 3.5W

Engineered for reliability and efficiency, the Pilz PNOZ 1 24VDC 3S/1O Safety Relay 24VDC 3.5W combines proven safety technology with minimal power requirements. The three safety-rated outputs control multiple contactors simultaneously, while the auxiliary output provides diagnostic feedback to control systems. Ultra-low 3.5W power consumption reduces heat generation in control cabinets and allows use in solar-powered or battery-operated machinery where power availability is limited but safety integrity cannot be compromised.

Key Features

• Ultra-low 3.5W power consumption for energy-efficient operation
• Three safety outputs for controlling multiple protective devices
• One auxiliary output for PLC feedback and status indication
• 24V DC supply voltage compatible with standard control systems
• Forced-guided contacts ensure fail-safe switching performance
• Compact housing design for space-constrained installations

Typical Applications

• Emergency stop circuits on battery-powered mobile machinery and AGVs
• Solar-powered equipment requiring minimal power consumption
• Robotic systems with energy management requirements
• Portable machinery and temporary installation safety systems
• Remote monitoring stations with limited power availability
• Control panels requiring heat reduction and energy optimization

Technical Specifications

• Product Name: Pilz PNOZ 1 24VDC 3S/1O Safety Relay
• Type: Emergency Stop Safety Relay
• Supply Voltage: 24V DC
• Power Consumption: 3.5W
• Safety Outputs: 3 safety-rated outputs (3S)
• Auxiliary Outputs: 1 auxiliary output (1O)
• Mounting: 35mm DIN rail
• Certifications: CE marked, complies with EN ISO 13849-1

📩 Contact us for pricing, availability, and delivery information.
